源码窗户
设备型号
现场测试设备无设备型号
协议未声明设备型号与支持设备型号
配置参数
类型 | 参数 | 必填 | 说明 |
---|---|---|---|
sourcecode_window | channel | 是 | 串口号 |
address | 是 | 设备地址(1~255) | |
readInterval | 否 | 读取时间间隔(默认为5,0为不读取) |
配置示例
type | config |
---|---|
sourcecode_window | channel=0,address=0,readInterval=5 |
设备通道
通道 | 类型 | 说明 |
---|---|---|
open | Button | 打开窗户 |
close | Button | 关闭窗户 |
stop | Button | 停止窗户 |
position | Number | 当前位置,百分比,0-100 |
mode | Enum | 当前模式,值为:flatopen、uprevolve |
